CS-72A
 Master View
2 Port Desktop KVM Switch
CS-72AC
The KVM (Keyboard, Video, Mouse) switch is a control unit that allows access to two computers from a single console (keyboard, monitor, and mouse). With its custom designed connectors, the significantly reduces the number of ports required for a 2 port KVM switch. The design features a custom SPHD-15 male connector for the keyboard, video, and mouse, and SPHD-15 female connectors for the cables that connect the switch to the computers..
Features



  • 2 Computers can share a Single Console (Monitor, PS/2 Keyboard and Mouse)
  • Auto scan function to monitor computer operation
  • Supports Microsoft IntelliMouse and the scrolling wheel on most mice
  • Logical connector layout - SPHD-15 connectors at rear panel for PC and console connections
  • Superior video quality - supports resolution of up to 2048 x 1536; DDC2B
  • Power on detection - automatically switching to the first powered on port
  • Easy to operate - Computer selection via push button switches or hotkeys
  • Non-powered
  • OS Compatibility: DOS、WIN 98、WIN ME、WIN NT、WIN 2K、WIN XP、WIN 2003 and LINUX. Mac 8.6/9/10 and SUN Solaris 8/9 (with optional adapter)

Package Contents
  • 1x 2 Port PS/2 KVM Switch
  •  2x KVM Cables (1.2m)
  •  1x Console Adapter Cable (50cm)
  •  1x Quick Start Guide
  •  1x User Manual

Specifications
Function
Specification
PC Connection Direct 2
Port Selection Push Button / Hot Keys
LEDs Selected 2
Emulation  Keyboard PS/2
Mouse
Connectors      Console
 Keyboard 1 x SPHD-15 Male (Yellow)
 Video
Mouse
Computer
  Keyboard 2 x SPHD-15 Female (Yellow)
Video
 Mouse
VGA Resolution 2048 x1536@60Hz, DDC2B
Scan Interval 5 sec.
Housing Metal
Weight 316 g
Power consumption
 DC 9V, 0.9W
Cable Requirement 2L-5202P (PS/2; 1.8 m) / 2L-5203P (PS/2; 3 m)
2L-5202UP (USB; 1.8m) / 2L-5203UP (USB; 3m)
Dimensions 125 x 81.5 x 25 mm (L x W x H)

Street Price £47.00 SPECIAL OFFER Now £30.00

All prices quoted on this web site are Estimated Street Prices for end-users and exclude Delivery & VAT.

Most items are in stock for next day delivery. Please fax through orders to 0118 988 7301 or e-mail us with your requirements , in either case full contact details such as delivery address, contact phone and fax numbers, together with Credit/Debit card details will be required. Credit cards are accepted subject to a 2% surcharge.  No surcharge on Switch,  Delta or Solo Debit cards. If you prefer not to send your card details via e-mail we will gladly call you back the next day to take these details.

For larger quantities and Computer Trade discounts please call us on 0118 988 7300 or e-mail us with full contact details . If you already hold an account with AVD the goods will be dispatched the same day. New trade account applications can also be dispatched the same day provided a suitable Debit / Credit card can be quoted.
