For 2 Console, 16 port Matrix Switch (KM-0216) Click here For 4 Console, 32 port Matrix Switch (KM-0432) Click here
Rear View Related Products 2 Console, 16 port Matrix Switch KM-0216 2 console 16-port high density Matrix KVM switch in 1U height 4 Console, 32 Server Matrix KVM Switch KM-0432 4 console 32-port high density Matrix KVM switch in 1U height	PS/2 Console Module (KA-9222) PS/2 Console Module Features One PS/2 console can control a local computer and a remote Matrix KVM Switch Toggle focus between your work PC and your KVM Switches / servers ASIC Built In for Greater Reliability and Compatibility Category 5 UTP Ethernet cable to connect the Matrix KVM Switch High resolution video - Up to 1024x768 @ 150 m (max.) Function Requirements A VGA, SVGA or Multisync monitor capable of the highest resolution that you will be using on any computer in the installation. A PS/2 style keyboard A PS/2 style mouse For optimal signal integrity and to simplify layout, a high quality Console Module to Local PC cable (with custom SPHD-15 connector) is included with the Console Module. No additional cable purchase is necessary. Package Contents 1 KA9222 Console Module 1 Custom KVM Cable 1 AC Power Adapter 1 Quick Start Guide 1 Registration Card Specifications Function KA9222 PC Selection Push Button, Hotkeys, OSD PC Connection Direct 1   To KM0432/0216 16/32 Connectors Computer Side 1 x SPHD-15 (F) Yellow   Console Side 1 x Mini-DIN-6 (F) Green 1 x Mini-DIN-6 (F) Purple 1 x HDB-15 (F) Blue   Link 1 x RJ-45 (F) Black   Power Port 1 x DC Jack (F) Black LEDs Remote 1 x Orange @ Front   Local 1 x Orange @ Front   Link 1 x Green @ Front Button Select 1 x Temperately Switch Normal / Recover 1 x Slide Switch Power Consumption DC 5V Keyboard/Mouse Emulation PS/2, Sun, USB (PC, Mac, SUN) Scan Interval 1 ~ 255 secs. Resolution 1024 x 768 @ 150M, DDC2B Operation Temperature 0~ 50°C Storage Temperature -20~ 60°C Humidity 0 ~ 80% RH, NC Enclosure Metal Weight 730 g Dimension 200 x 74.5 x 42 mm
Street Price £250 (KA-9222) £210 (KA-9220 - No local console) All prices quoted on this web site are Estimated Street Prices for end-users and exclude Delivery & VAT. Most items are in stock for next day delivery. Please fax through orders to 0118 988 7301 or e-mail us with your requirements , in either case full contact details such as delivery address, contact phone and fax numbers, together with Credit/Debit card details will be required. Credit cards are accepted subject to a 2% surcharge.  No surcharge on Switch,  Delta or Solo Debit cards. If you prefer not to send your card details via e-mail we will gladly call you back the next day to take these details. For larger quantities and Computer Trade discounts please call us on 0118 988 7300 or e-mail us with full contact details . If you already hold an account with AVD the goods will be dispatched the same day. New trade account applications can also be dispatched the same day provided a suitable Debit / Credit card can be quoted.
ALTUSEN and the ALTUSEN logo are registered trademarks of ATEN International Co. Ltd. All other trademarks belong to the respective owners.
